Diaphragm Vacuum Pump

• Application
• Other, Chemical, Laboratory, Industrial

• Caliber
• Standard

• Capacity
• 15-20 L/min

• Control System
• Manual On/Off

• Discharge Pressure
• 2.3 Kg/cm2

• Features
• Oil-free, Maintenance-free, Corrosion-resistant, Lightweight, Silent Operation

• Flow Rate
• ~15-20 L/min

• Frequency
• 50 Hz

• Fuel Type
• Other, Electric

• Inlet/Outlet
• 1/4 BSP

• Material
• Aluminum alloy and engineering plastics

• Max Suction
• 550 mm Hg

• Mounting Type
• Foot Mounted

• Noise Level
• < 60 dB

• Power
• Other, 80W - 100W

• Pressure
• Other, 2.3 Kg/cm2 (Max)

• Priming
• Self-priming

• Pump Type
• Other, Compressor Cum Vacuum Pump

• Seals Type
• Oil-Free Diaphragm

• Speed
• 1400-1450 RPM

• Standard
• IS/ISO Certified

• Structure
• Other, Compact, Portable

• Suction Type
• Positive displacement

• Theory
• Other, Diaphragm Pump

• Usage
• Other, Laboratory, Medical, Filtration, Vacuum and Compressor applications

• Voltage
• 220V / 50Hz

• Working Temperature
• 5C to 40C

• Application
• Other, Vacuum Filtration, Suction and Compression

• Caliber
• 6 mm

• Capacity
• 20 LPM

• Control System
• Manual ON/OFF

• Discharge Pressure
• 2.1 kg/cm2

• Features
• Oil-free, Low Noise, Maintenance Free

• Flow Rate
• 20 L/min

• Frequency
• 50 Hz

• Fuel Type
• Other, Electric

• Inlet/Outlet
• 6 mm Dia Hose Nozzle

• Material
• EPDM Diaphragm, Aluminum Alloy Housing

• Max Suction
• 650 mm Hg (Vacuum)

• Mounting Type
• Rubber Foot Mount

• Noise Level
• < 60 dB

• Power
• Other, 1/8 HP

• Pressure
• Other, Max 30 psi (2.1 kg/cm2)

• Priming
• Self-priming

• Pump Type
• Other, Diaphragm Compressor Cum Vacuum Pump

• Seals Type
• Oil-Free Diaphragm

• Speed
• 1400 rpm

• Standard
• CE Marked

• Structure
• Other, Compact, Bench-top

• Suction Type
• Single Stage

• Theory
• Other, Diaphragm Pump

• Usage
• Other, Laboratory, Filtration, Vacuum and Compression Applications

• Voltage
• 230V AC, 50 Hz

• Working Temperature
• 5C to 40C

• Application
• Other, Chemical, Pharmaceutical, Laboratory Use

• Caliber
• 6 mm

• Capacity
• 35 L/min

• Control System
• Manual On/Off

• Discharge Pressure
• Up to 2.5 kg/cm2

• Features
• Oil-Free, Maintenance-Free, Portable

• Flow Rate
• 35 L/min

• Frequency
• 50/60 Hz

• Fuel Type
• Other, Electric

• Inlet/Outlet
• 6 mm (approx)

• Material
• Aluminium & Engineering Plastic

• Max Suction
• 650 mm Hg

• Mounting Type
• Table Top / Portable

• Noise Level
• <60 dB

• Power
• Other, 60 Watts

• Pressure
• Other, Max. 2.5 kg/cm2

• Priming
• Self-Priming

• Pump Type
• Other, Oil-Free Diaphragm Compressor Cum Vacuum Pump

• Seals Type
• Diaphragm Sealed

• Speed
• 1400 rpm

• Standard
• CE Certified

• Structure
• Other, Double Head

• Suction Type
• Double head

• Theory
• Other, Diaphragm Pump

• Usage
• Other, Laboratory, Vaccum & Compressor Applications

• Voltage
• 220V / 110V

• Working Temperature
• -10C to 60C

• Application
• Other, Filtration, Vacuum Distillation, Solvent Extraction

• Caliber
• Standard

• Capacity
• 28 Liters per Minute

• Control System
• On/Off Switch

• Discharge Pressure
• 2.6 kg/cm2

• Features
• Oil-Free, Low Maintenance, Portable, Corrosion Resistant

• Flow Rate
• 28 LPM (Free Air Displacement)

• Frequency
• 50 Hz

• Fuel Type
• Other, Electric

• Inlet/Outlet
• 1/4 BSP

• Material
• Aluminum Alloy Body and PTFE Diaphragm

• Max Suction
• 650 mm Hg (Vacuum)

• Mounting Type
• Base Mounted

• Noise Level
• <60 dB

• Power
• Other, 1/8 HP

• Pressure
• Other, 2.6 kg/cm2 (Max)

• Priming
• Self-Priming

• Pump Type
• Other, Diaphragm Compressor Cum Vacuum Pump

• Seals Type
• Diaphragm Sealing

• Speed
• 1420 RPM

• Standard
• Laboratory Standard

• Structure
• Other, Single Head, Oil-Free

• Suction Type
• Dry Suction

• Theory
• Other, Diaphragm Pump

• Usage
• Other, Laboratory Applications

• Voltage
• 230V AC, 50 Hz

• Working Temperature
• 5C to 50C

• Application
• Other, Chemical, Pharmaceutical, Medical, Laboratory

• Caliber
• Standard

• Capacity
• 30 liters/minute

• Control System
• Manual

• Discharge Pressure
• Up to 2.0 kg/cm2

• Features
• Corrosion Resistant, Maintenance Free, Continuous Duty

• Flow Rate
• 30 liters/minute

• Frequency
• 50 Hz

• Fuel Type
• Other, Electrical

• Inlet/Outlet
• 1/4 BSP

• Material
• Aluminum Body, Diaphragm made of Nitrile Rubber

• Max Suction
• 650 mm Hg

• Mounting Type
• Rubber Feet for Anti Vibration

• Noise Level
• < 60 dB

• Power
• Other, 60 Watts

• Pressure
• Other, Approximately 2.0 kg/cm2

• Priming
• Self-Priming

• Pump Type
• Other, Oil-Free Diaphragm

• Seals Type
• Diaphragm Type Seal

• Speed
• 1450 RPM

• Standard
• Laboratory Grade

• Structure
• Other, Portable Table Top

• Suction Type
• Oil-Free

• Theory
• Other, Diaphragm Compressor/Vacuum Pump

• Usage
• Other, Laboratory, Gas Sampling, Filtration, Vacuum Distillation, Compressing Air

• Voltage
• 220 V AC, 50 Hz

• Working Temperature
• 5C to 40C

• Application
• Other, Filtration, Vacuum Distillation, Suction, Compressor Uses

• Caliber
• Compact

• Capacity
• Continuous Operation

• Control System
• Manual

• Discharge Pressure
• Up to 2.2 Bar

• Features
• Oil-Free, Maintenance-Free, Lightweight, Portable

• Flow Rate
• 40 L/min (Approx.)

• Frequency
• 50 Hz

• Fuel Tank Capacity
• Not Applicable (Electric Driven)

• Fuel Type
• Other, Electric

• Inlet/Outlet
• 6 mm Hose Nozzle

• Material
• Aluminium Body, Diaphragm Neoprene Rubber

• Max Suction
• -650 mm Hg (Vacuum)

• Mounting Type
• Table Top

• Noise Level
• Low (approx. 60 dB)

• Power
• Other, 1/16 HP

• Pressure
• Other, 2.2 Bar (Max Discharge)

• Priming
• Self Priming

• Pump Type
• Other, Diaphragm / Oil-Free Pump

• Seals Type
• Diaphragm Seal

• Speed
• 2800 RPM

• Standard
• ISI Marked Motor

• Structure
• Other, Portable, Oil-less

• Suction Type
• Dry Suction

• Theory
• Other, Diaphragm Compressor Cum Vacuum Pump

• Usage
• Other, Laboratory / Industrial Use

• Voltage
• 220 V / 50 Hz AC

• Working Temperature
• 5C - 40C

• Application
• Other, Laboratory, Industrial, Analytical Instruments, Filtration

• Capacity
• 30 LPM

• Control System
• Manual ON/OFF Switch

• Discharge Pressure
• 2.1 kg/cm2

• Features
• Oil-free, Maintenance-free, Portable

• Flow Rate
• 30 Litres/min

• Frequency
• 50 Hz

• Fuel Type
• Other, Electric

• Inlet/Outlet
• 1/4 inch (6 mm) Hose Nozzle

• Material
• Aluminium Die Cast Body with Oil-free Diaphragm

• Max Suction
• 650 mm Hg

• Mounting Type
• Rubber Foot Mount

• Noise Level
• <60 dB

• Power
• Other, 1/16 HP

• Pressure
• Other, 2.1 kg/cm2

• Priming
• Self Priming

• Pump Type
• Other, Oil-Free Diaphragm Compressor Cum Vacuum Pump

• Seals Type
• Diaphragm Sealed

• Speed
• 1440 RPM

• Standard
• IS Standard

• Structure
• Other, Single Head, Oil-less

• Suction Type
• Dry Suction

• Theory
• Other, Diaphragm Pump

• Usage
• Other, Vacuum Filtration, Air Suction, Air Compression

• Voltage
• 220V-240V AC, 50Hz

• Working Temperature
• 5C to 50C

• Application
• Other, Filtration, Vacuum Drying, Rotary Evaporators

• Caliber
• Standard

• Capacity
• 20-25 Liters per Minute

• Control System
• Manual On/Off

• Discharge Pressure
• Up to 2.1 Kg/cm2

• Features
• Oil Free, Low Maintenance, Compact Design

• Flow Rate
• 20-25 LPM

• Frequency
• 50 Hz

• Fuel Type
• Other, Electric

• Head Size
• Compact

• Inlet/Outlet
• 1/4 BSP

• Material
• Aluminum Die Cast

• Max Suction
• >650 mm Hg

• Mounting Type
• Base Mounted

• Noise Level
• < 60 dB

• Power
• Other, 1/8 HP

• Pressure
• Other, 2.1 Kg/cm2 (Max)

• Priming
• Self Priming

• Pump Type
• Other, Compressor Cum Vacuum Pump

• Seals Type
• Nitrile / PTFE

• Speed
• 1440 RPM

• Standard
• Lab Grade

• Structure
• Other, Diaphragm Type

• Suction Type
• Oil Free

• Theory
• Other, Diaphragm Pump

• Usage
• Other, Compressor & Vacuum Applications

• Voltage
• 220 V / 50 Hz AC

• Working Temperature
• 5C-40C

• Application
• Other, Compressor & Vacuum Pump

• Caliber
• 6 mm

• Capacity
• 10 L/min

• Control System
• Manual

• Discharge Pressure
• 2.5 bar (Max)

• Features
• Oil-free, Maintenance free, Portable

• Flow Rate
• 10 L/min

• Frequency
• 50Hz

• Fuel Type
• Other, Electric

• Inlet/Outlet
• 6 mm Hose Barb

• Material
• Aluminium & Engineering Plastic

• Max Suction
• 0.08 Mpa

• Mounting Type
• Foot Mounted

• Noise Level
• <60 dB(A)

• Power
• Other, 60 Watts

• Pressure
• Other, 2.5 bar

• Priming
• Self-priming

• Pump Type
• Other, Oil-free Diaphragm

• Seals Type
• Diaphragm

• Speed
• 1400 RPM

• Standard
• CE Certified

• Structure
• Other, Single-head Diaphragm

• Suction Type
• Dry

• Theory
• Other, Diaphragm Pump

• Usage
• Other, Laboratory, Industrial

• Voltage
• 220V / 50Hz

• Working Temperature
• 5C to 40C

• Application
• Other, Medical, Laboratory, Filtration, Gas Sampling

• Caliber
• 6 mm

• Capacity
• 10 Litres per Minute

• Control System
• Manual Switch

• Discharge Pressure
• 30 PSI (max)

• Features
• Oil-less, Maintenance-Free, Portable

• Flow Rate
• 10 LPM

• Frequency
• 50 Hz

• Fuel Type
• Other, Electric

• Head Size
• Standard

• Inlet/Outlet
• 1/4 (6 mm) Hose Barb

• Material
• Aluminium Body with Diaphragm Rubber

• Max Suction
• 550 mm Hg

• Mounting Type
• Table Top

• Noise Level
• < 60 dB

• Power
• Other, 1/20 HP (37 Watts)

• Pressure
• Other, 2.1 kg/cm2 (max)

• Priming
• Self Priming

• Pump Type
• Other, Oil-less Diaphragm Pump

• Seals Type
• Diaphragm

• Speed
• 1440 RPM

• Standard
• Laboratory Standard

• Structure
• Other, Single Head, Monoblock

• Suction Type
• Positive Displacement

• Theory
• Other, Diaphragm Pump

• Usage
• Other, Vacuum & Compression, Laboratory

• Voltage
• 220V AC

• Working Temperature
• 5C to 40C

• Application
• Other, Filtration, Vacuum Distillation, Gas Transfer, Laboratory Use

• Caliber
• Standard

• Capacity
• 20 LPM

• Control System
• Manual

• Discharge Pressure
• 2.1 kg/cm2

• Features
• Corrosion Resistant, Maintenance Free, Oil Free Operation

• Flow Rate
• 20 LPM

• Frequency
• 50 Hz

• Fuel Type
• Other, Electric

• Head Size
• Standard

• Inlet/Outlet
• 1/4 BSP

• Material
• Aluminium Casting & Teflon Diaphragm

• Max Suction
• 650 mm Hg

• Mounting Type
• Bench Top

• Noise Level
• Low

• Power
• Other, 1/8 HP

• Pressure
• Other, 2.1 kg/cm2

• Priming
• Self Priming

• Pump Type
• Other, Oil Free Diaphragm

• Seals Type
• Diaphragm Type

• Speed
• 1440 RPM

• Standard
• Conforming to IS: 8437

• Structure
• Other, Portable Bench Model

• Suction Type
• Single Stage

• Theory
• Other, Diaphragm Compressor Cum Vacuum Pump

• Usage
• Other, Laboratory / General Purpose

• Voltage
• 220V AC

• Working Temperature
• Up to 40C
